Modular Screw Elements
Customized mixing profiles for your specific compound requirements.
Custom Machinery
Twin Screw, Co-Rotating and Counter Rotating Extruder
Varying from Ø14–Ø97 mm (capable up to Ø150 mm, L/D 60).
At Testron Engineering, we manufacture co-rotating twin-screw extruders ranging from Ø14 mm to Ø97 mm (capable up to Ø150 mm, L/D 60), designed to support everything from R&D trials to full-scale industrial production.
Built at our manufacturing facility in Bangalore, India, each machine is engineered with precision screw profiles, heavy-duty gearboxes, and modular barrel systems — ensuring superior mixing, high torque stability, and long service life.
Whether you are developing a new formulation or running continuous masterbatch production, our extruders deliver consistent output, optimized energy usage, and process flexibility.
Key Strengths
What Sets Our Extruders Apart
- In-house screw & barrel manufacture (accurate metallurgy & hard-facing)
- Heavy-duty gearboxes and shafts built for high torque life
- Custom screw geometries for dispersive mixing and devolatilization
- Integrated PLC controls, dosing & downstream options
- Training, commissioning and Annual Maintenance Contracts (AMC)
Application Areas
Industries & Compounds We Serve
- Color and Additive Masterbatch
- Polymer Compounding (Commodity and Bio)
- Engineering Plastics
- Filler & Mineral Compounds
- Reprocessing & Recycling
- Specialty Polymer Blends
- High-performance Materials
- Grafting
- Pultrusion (LFRTP)
Unified Technical Specifications
14 mm – 97 mm Series
| Parameter | Specification Range |
|---|---|
| Screw Diameter | 14 mm – 97 mm |
| Screw Type | Co-rotating, modular segmented design |
| L/D Ratio | 24:1 – 60:1 (customisable) |
| Throughput | 0.5 kg/hr (30 ml) – 1200+ kg/hr @ density 1 |
| Screw Speed | 50 – 1200 rpm (VFD-controlled) |
| Main Motor Power | 1 HP – 500+ HP (application dependent) |
| Gearbox | Heavy-duty, high-torque transmission & coupling system |
| Heating Zones | 4 – 16 PID angular phase-controlled zones |
| Max Processing Temperature | Up to 400°C (depending on material) |
| Control System | PLC + HMI interface with recipe control |
| Feeding Options | Gravimetric / Volumetric / Density Feeders / Forced spray Lubrication System |
| Downstream Options | Strand Pelletizer / Underwater Pelletizer / Die Face Cutter / Conveyer |
| Cooling System | Water cooling / forced air system / Plate type heat exchanger |
| Electrical Supply | 380–440V, 3-Phase, 50/60Hz & 110V |
| Warranty | 24 Months Standard (physical damage; electrical damage excluded) |
*Throughput depends on polymer type, filler percentage, screw configuration, and L/D ratio.
Key Engineering Advantages
Built for Demanding Production Environments
High-Torque Gearbox Design
Engineered for demanding compounds and sustained high-load operation.
Optimized Barrel Metallurgy
Wear-resistant materials selected for your filler and abrasive content.
Stable Melt Pressure
Low vibration design for consistent output and product quality.
Easy Maintenance
Quick screw replacement and accessible service points reduce downtime.
Long Operational Life
Designed for continuous industrial performance year after year.
Customization Capability
Every Line Engineered to Your Process
Every extrusion line is built based on:
- Polymer additive combination
- Required output (kg/hr)
- Desired dispersion quality
- Energy optimization goals
- Automation level required
- Future scalability planning
We do not supply standard machines — we engineer solutions aligned with your process and performance expectations.
Support Beyond Installation
Long-Term Partnership for Operational Success
To ensure long-term operational success, we provide:
- On-site commissioning
- Operator & maintenance training
- Spare screw, shaft and barrel supply
- Annual Maintenance Contracts (AMC)
- Process optimization consultation
Engineered for Precision. Built for Performance. Scaled for Growth.
Our Ø14–Ø97 mm Twin-Screw Extruder Series represents a complete, scalable solution for modern polymer processing industries across India, UAE, GCC and global markets.
See Our Machinery in Action
From lab-scale R&D to industrial throughput, Testron extruders are configured for your material, output, and production environment.
Let's Build Your Next Production Advantage
Speak with our engineering team about custom machinery, precision spares, or lifecycle servicing for your extrusion line.
